The QBM11-3 is a compact, advanced single-phase two-wire electricity conventional meter capable of measuring active and reactive energy as well as maximum demand, with data displayed on an LCD screen. Compliant with DLMS-COSEM standards, it supports meter reading via IrDA and RS485 communication. Its built-in Real-Time Clock (RTC) enables multi-tariff functionality and seasonal switching, while data is stored in non-volatile memory.
Comprehensive Quad-Quadrant Sampling: Fully capable of running bi-directional measurement schemas mapping both active energy and reactive energy factors under varying heavy load demands.
Standardized Utility Interoperability: Engineered for native DLMS/COSEM compliance, ensuring drop-in compatibility with central Head-End Systems (HES) over dual-channel communication media (RS485 terminal line + IrDA wireless).
RTC-Driven Synchronization: Driven by an industrial-grade internal Real-Time Clock (RTC) ensuring microsecond seasonal switching, paired with full RWP visibility and a continuous 12-month frozen billing memory stack.
1. Bi-directional measurement of active energy.
2. The meter has a multi-tariff (TOU) measurement function.
3. The LCD can display real-time clock, current, voltage, and active power, etc.
4. Record and display the data of the current month’s Maximum demand.
5. Store the monthly cumulative active energy of the last 12 months.
6. Base cover and terminal cover open detection and record.
7. Display readable without main power (RWP).
8. Support real-time-clock function
9. DLMS compliance
10.IrDA remote reading
